Wall Mounted Bathroom Fan

Wall Mounted Bathroom Fan

Wall Mounted Bathroom Fan for compact bathroom ventilation with space-saving wall-mount design and reliable moisture extraction

PROJECT FIT
Wall Mounted Bathroom Fan for compact bathroom ventilation with space-saving wall-mount design and reliable moisture extraction
PERFORMANCE RANGE
3 APC models · wall-mount design · compact bathroom ventilation for exterior-wall discharge
Project quotation availableAdd this product to your quote, then include your preferred model and project requirements in the inquiry.

This product is currently out of stock and unavailable.

Add to quote
Exhaust fan selection

Wall Mounted Bathroom Fan Selection Snapshot

Confirm whether a wall-mounted bathroom fan fits the exterior wall discharge route before final model approval. Final quotation depends on the selected APC model, wall opening, grille or shutter clearance, rain protection, backdraft control, voltage and quantity.

Project fitdirect wall exhaust
Applicationbathrooms and utility rooms with exterior wall discharge
Project detailsConfirm wall opening, grille, rain protection and backdraft control
Selection rule

Do not approve the model from the product name alone. Confirm mounting route, duct path, opening size, airflow/noise target and power supply.

Specification check

Confirmed performance by APC model

Wall Mounted Bathroom Fan confirmed specification table
Model Size (mm) Voltage (V) Frequency (Hz) Power (W) Airflow (m³/min) Noise (dB(A))
APC10-S-N 100 220 50 9 1.5 39
APC15-2S-N 150 220 50 16 3.0 39
APC20-3S-N 200 220 50 18 4.2 43

Source note: Model, size, voltage, frequency, power, airflow and noise values are read from the APC product table shown in the linked source PDF on this page. Confirm wall opening, exterior grille, rain protection and backdraft control against the site condition for quote review.

100 mm modelAPC10-S-N keeps power low at 9 W and suits compact bathroom wall exhaust routes.
150 mm modelAPC15-2S-N raises airflow to 3.0 m³/min when the room or duct route needs more extraction.
200 mm modelAPC20-3S-N reaches 4.2 m³/min, but the larger opening and 43 dB(A) noise level should be checked before approval.
Application fit

Where this exhaust fan fits

Best use

bathrooms and utility rooms with exterior wall discharge.

Selection factors

Confirm wall opening, grille, rain protection and backdraft control.

Avoid

Do not select only by product photo or generic category name.

Related hub

Compare all exhaust fan models.

Selection guide

Selection guide

1. Define room need

Bathroom, utility room, commercial restroom, workshop or sidewall exhaust.

2. Confirm air route

Ceiling duct, direct wall route, shutter opening or panel installation.

3. Match performance

Confirm airflow, noise target, duct length and bends.

4. Request confirmation

Send model, quantity, voltage and destination for selection support.

Fit check

Compare the options

Use the official Exhaust Fans Collection Hub when comparing ceiling, wall, EC bathroom and shutter exhaust fan options.

Core Engineering Features

Wall Mounted Bathroom Fan Selection Snapshot set against the published values on this page. Every point below is taken from this model’s own data.

Project fitdirect wall exhaust
Applicationbathrooms and utility rooms with exterior wall discharge
Project detailsConfirm wall opening, grille, rain protection and backdraft control
100 mm modelAPC10-S-N keeps power low at 9 W and suits compact bathroom wall exhaust routes.
150 mm modelAPC15-2S-N raises airflow to 3.0 m³/min when the room or duct route needs more extraction.
200 mm modelAPC20-3S-N reaches 4.2 m³/min, but the larger opening and 43 dB(A) noise level should be checked before approval.

Quality Assurance & Warranty

Fan orders are checked at the factory before shipping, because published airflow and pressure only hold if the delivered unit matches its table row.

Applied to this model: Project fit direct wall exhaust, Application bathrooms and utility rooms with exterior wall discharge. These checks are run against that specification before the unit ships.

Airflow and pressure checkChecks cover motor start-up, impeller balance, airflow and static pressure verification, noise review and model-to-table parameter matching.
Documented complianceCE, RoHS and related files cover the listed fan families; see the documents section below.
Warranty supportWarranty for fan orders is confirmed with the quotation for your destination market.
Service parts for fansImpellers, motor capacitors, mounting brackets and common service items.

OEM/ODM & Supply Options

For distributors and contractors working on ventilation projects, the supply side adapts to your market instead of one fixed fan build.

For this model (Project fit direct wall exhaust, Application bathrooms and utility rooms with exterior wall discharge), the OEM route can start from that base specification rather than a blank sheet.

OEM/ODMBadging, packaging and control options for fan orders, including branded cartons and manual inserts.
Airflow and pressure variantsModel selection, motor power and voltage options are reviewed against your duct calculation.
Voltage & plug optionsVoltage and plug configuration for this product line can be reviewed during quotation.
Documentation & bulk supplyCatalogues, technical sheets, available certificates, volume pricing and distributor programs for this product line.
Order quantity & lead timeMinimum order quantity, sampling and production lead time are confirmed per model and order volume — see the B2B supply page for how sourcing enquiries are handled.

Documents & Compliance

Download the EC wall-mounted exhaust fan datasheet used for the technical values on this page, and review the relevant compliance documents.

Confirm the exact model, destination-market requirements and current documentation before quotation or project documentation.

View all certifications and compliance documents by product scope

Frequently asked questions

How do I choose this model?

Start from the installation route and room use, then confirm the exact model datasheet or database row.

Can I use generic fan values?

No. Use only confirmed source values for airflow, noise, power and dimensions.

What should I send for quotation?

Send room type, opening size, duct path, airflow target, voltage, quantity and destination.

What Buyers Say

Verified buyer feedback on this product line from the group’s KCVENTS retail store. We publish reviews as written, including critical feedback, so you can judge the product on real experience rather than marketing copy.

★★★★★
The fan works as described. Very simple to operate. A bit noisy but in lowest speed is ok!
dumitru D. · verified buyer · KCVENTS retail store
★★★★★
Not so quiet but powerful instead. 1 speed for night is ok.
Arturs S. · verified buyer · KCVENTS retail store
★★★★☆
It works OK, a little bit low quality of housing.
Joze H. · verified buyer · KCVENTS retail store

Reviews are for the reversible 4/6-inch wall exhaust fan and equivalent models in this series. Individual results vary with installation and site conditions.

Product inquiry

Confirm the published specifications, then add this product to your quote list.

model

APC10-S-N, APC15-2S-N, APC20-3S-N
