High Pressure Air Cabinet Fan

Cabinet fan selection

Cabinet Fan Selection Snapshot

High Pressure Air Cabinet Fan range for high-static-pressure cabinet ventilation with industrial-grade ducted airflow. Check the model table for airflow, static pressure, and dimensions before specifying.

Source: CHIC GROUP HVAC 2026 catalogue (p.29 plus PIM DT high-confidence rows · high-confidence PIM rows from Cabinet / Air Conditioning Fan Series.

Project fitDT high-pressure cabinet fan for long-duct or high-resistance ventilation

Sample modelsDT28-6000 / DT30-10000 / DT30-8000 / DT32-12000

Project detailsConfirm DT model, target airflow/static pressure, duct length, elbows, outlet size, voltage, motor location and maintenance access

Source note

Only high-confidence rows are shown. Unrelated smoke-exhaust models are excluded from this Cabinet/KTJ/DT batch.

Documented checks

High-confidence model checks

High Pressure Air Cabinet Fan technical and selection table
Modèle	Voltage	Power W	Débit d'air m³/h	Static pressure Pa	Bruit dB(A)	Outlet / filter size	Source
DT28-6000	380	1500	6500-4800	520-710	64	405×285	13
DT30-10000	380	3000	10500-8500	720-800	70	430×300	13
DT30-8000	380	2200	8500-6500	640-740	67	430×300	13
DT32-12000	380	4000	12500-9000	740-850	73	405×330	13

Application fit

Where this cabinet fan fits

Cabinet fans are selected when a project needs enclosed airflow, easier service access and a cleaner installation than an open fan. For kitchen or high-resistance routes, static pressure and oil/filter access matter as much as airflow.

Use the model table as a starting point, then confirm duct resistance, opening size and maintenance clearance for final selection.

Typical buyer checks

Airflow and static pressure at working point
Voltage/frequency and motor protection requirement
Inlet/outlet opening and filter size
Inspection door, oil/water drain and cleaning access

Selection guide

Cabinet fan selection guide

1. Define duty

General ventilation, filtered cabinet airflow, kitchen exhaust or long duct/high-pressure route.

2. Match airflow + pressure

Do not choose by airflow alone; static pressure and duct losses decide the usable model.

3. Check installation

Confirm opening size, cabinet dimensions, mounting space and maintenance clearance.

4. Confirm model

Send duct route, airflow target, voltage and site photos for quote review.

Comparer

KTJKTJ-GDT positioning

KTJ is suited to general cabinet ventilation, KTJ-G is better for filter/oil-management cabinet use, and DT high-pressure cabinet fans are better for longer or higher-resistance duct routes. HTFC smoke-exhaust products are a separate family and are not merged into this table.

Core Engineering Features

Cabinet Fan Selection Snapshot set against the published values on this page. Every point below is taken from this model’s own data.

Project fitDT high-pressure cabinet fan for long-duct or high-resistance ventilation

Sample modelsDT28-6000 / DT30-10000 / DT30-8000 / DT32-12000

Project detailsConfirm DT model, target airflow/static pressure, duct length, elbows, outlet size, voltage, motor location and maintenance access

Voltage380

Power W1500

Débit d'air m³/h6500-4800

Quality Assurance & Warranty

Fan orders are checked at the factory before shipping, because published airflow and pressure only hold if the delivered unit matches its table row.

Applied to this model: Project fit DT high-pressure cabinet fan for long-duct or high-resistance ventilation, Sample models DT28-6000 / DT30-10000 / DT30-8000 / DT32-12000. These checks are run against that specification before the unit ships.

Airflow and pressure checkChecks cover motor start-up, impeller balance, airflow and static pressure verification, noise review and model-to-table parameter matching.

Documented complianceCE, RoHS and related files cover the listed fan families; see the documents section below.

Warranty supportWarranty for fan orders is confirmed with the quotation for your destination market.

Service parts for fansImpellers, motor capacitors, mounting brackets and common service items.

OEM/ODM & Supply Options

For distributors and contractors working on ventilation projects, the supply side adapts to your market instead of one fixed fan build.

For this model (Project fit DT high-pressure cabinet fan for long-duct or high-resistance ventilation, Sample models DT28-6000 / DT30-10000 / DT30-8000 / DT32-12000), the OEM route can start from that base specification rather than a blank sheet.

OEM/ODMBadging, packaging and control options for fan orders, including branded cartons and manual inserts.

Airflow and pressure variantsModel selection, motor power and voltage options are reviewed against your duct calculation.

Voltage & plug optionsVoltage and plug configuration for this product line can be reviewed during quotation.

Documentation & bulk supplyCatalogues, technical sheets, available certificates, volume pricing and distributor programs for this product line.

Order quantity & lead timeMinimum order quantity, sampling and production lead time are confirmed per model and order volume — see the B2B supply page for how sourcing enquiries are handled.

Documents & conformité

Download the high pressure air cabinet fan datasheet used for the technical values on this page, and review the relevant compliance documents.

Download high pressure air cabinet fan datasheet (PDF)

Confirm the exact model, destination-market requirements and current documentation before quotation or project documentation.

View all certifications and compliance documents by product scope

Frequently asked questions

Can I select by airflow only?

No. Cabinet fan selection must include static pressure, duct route, elbows, inlet/outlet size and maintenance access.

Are all models listed?

No. The table shows high-confidence sample rows from the matched PDF/PIM source. Ask for the exact model datasheet before final order.

Is HTFC included in this page?

No. HTFC smoke-exhaust cabinet centrifugal fans require separate source handling and should not be mixed with KTJ/DT cabinet fan tables.

Product inquiry

Confirm the published specifications, then add this product to your quote list.
